Bastion M (burglary resistance, grade II, LFS 30P)
description
- Burglary resistance – EN 1143-1, Grade II.
- Fire resistance – LFS 30P according to EN 15659.
- Thickness of door – 92 mm
- Thickness of walls – 58 mm
- Patented, special type of Ultra High Performance Concrete
- Three way locking bolts.
- Integrated relocker, lock secured from drill attacks.
- Standard delivery with double-bit high security key lock with two keys.
- Anchoring to the floor and back wall.
- Color: RAL 7035 (light grey), also available in RAL 7024 (grey graphite).
Models
Name
External Dimensions, mm (HxWxD)
Internal Dimensions, mm (HxWxD)
Locking bolts
Number of shelves
Weight, kg
Volume, l
Package
Bastion-M 46
460x470x470
333x355x319
8
1
179
38
Type of pallet - 0.8x1.2,
Quantity on
the pallet - 3
Quantity on
the pallet - 3
Bastion-M 46
Bastion-M 50
500x510x510
373x395x359
8
1
220
53
Type of pallet - 0.8x1.2,
Quantity on
the pallet - 3
Quantity on
the pallet - 3
Bastion-M 50
Bastion-M 67
670x510x510
544x395x359
8
1
279
77
Type of pallet - 0.8x1.2,
Quantity on
the pallet - 2
Quantity on
the pallet - 2
Bastion-M 67
Bastion-M 60
610x680x510
483x565x359
8
1
305
98
Type of pallet - 0.8x1.2,
Quantity on
the pallet - 2
Quantity on
the pallet - 2
Bastion-M 60
Bastion-M 80
810x680x510
684x565x359
9
2
382
139
Type of pallet - 0.8x1.2,
Quantity on
the pallet - 2
Quantity on
the pallet - 2
Bastion-M 80
Bastion-M 99
990x510x510
864x395x359
9
2
370
123
Type of pallet - 0.8x1.2,
Quantity on
the pallet - 2
Quantity on
the pallet - 2
Bastion-M 99
Bastion-M 1068
1010x680x510
883x565x359
9
2
419
179
Type of pallet - 0.8x1.2,
Quantity on
the pallet - 2
Quantity on
the pallet - 2
Bastion-M 1068
Bastion-M 1368
1320x680x510
1193x565x359
10
3
572
242
Type of pallet - 0.8x1.2,
Quantity on
the pallet - 2
Quantity on
the pallet - 2
Bastion-M 1368
Bastion-M 1668
1660x680x510
1533x565x359
11
4
755
311
Type of pallet - 0.8x1.2,
Quantity on
the pallet - 2
Quantity on
the pallet - 2
Bastion-M 1668
